Video Outgoing-inspection:
Provided
Machinery Test Report:
Provided
Core Components:
PLC, Engine, Bearing, Gearbox, Gear
Plastic Processed:
PP, HDPE , ABS, PVC, PE, EVA, PE/PP, HDPE/PP
Place Of Origin:
Jiangsu, China
Brand Name:
DAWSON
Voltage:
440V/415V/380V/220V
Dimension(l*w*h):
4.4*3.4*3.6
Clamping Force (kN):
270
Screw Diameter (mm):
90 Mm
Output (kg/h):
130 Kg/h
Automation:
Automatic
No. Of Screw Heating Zone:
4
Screw Heating Power(kw):
10 KW
Extruder Motor Power(kw):
30 KW
Mold Platen Size(width)(mm):
660 Mm
Mold Platen Size(height)(mm):
680 Mm
Air Pressure(mpa):
0.8 MPa
Air Comsumption(m³/min):
2.2 M³/min
Die Head Heating Power(kw):
8 KW
Power (kw):
67
Weight (t):
11.3
Key Selling Points:
Easy To Operate
Warranty:
1 Year
Blow Molding Type:
Extrusion Blow Molding Machine
Maximum Application Size:
30L
Cooling Water Pressure:
0.6 MPA
Water Consumption:
100 L/Min
Mould Lifespan:
> 1,000,000 Cycles
Mold Material:
P20, 2316, S136H, Aluminum With Beryllium Copper.
Language Settings:
Chinese And English Operation Panel
Instructions Provided:
Instructions In Chinese And English
Labor Demand:
1~2 Operetor
Samples Provided:
If Required
Condition:
New
Warranty Of Core Components:
1 Year
Application:
Bottle, Jerry Can, Jar, Gallon
Applicable Industries:
Manufacturing Plant, Food & Beverage Factory, Farms, Food & Beverage Shops
Showroom Location:
Philippines
Year:
New
Hollow Part Volume:
30L
Accumulator Capacity(L):
0 L
