Extrusion Blow Molding Machine ABLB65
suitable for making plastic bottle, jars, small containers, jerrycans from 50ml to 5L, The whole blow molding machine is equipped with bilingual operation panel and automatic configuration from world famous brands to realize the advantages of simple operation and high automation.
| Name | Units | ABLB65II | ABLB75II |
| Max.product volume | L | 3.5 | 8 |
| Screw diameter | MM | 65 | 75 |
| Screw drive power | KW | 18.5 | 22 |
| Output of HDPE | KG/H | 75 | 100 |
| Oil pump drive power | KW | 7.5 | 7.5 |
| Clamping force | KN | 65 | 80 |
| Max.size of mold | MM | 320×350 | 400×430 |
| Template size | MM | 290×320 | 380×420 |
| Mold stroke | MM | 150-500 | 170-520 |
| Max.die diameter | MM | 170 | 170 |
| Size of machine | L×W×H | 3.9×2.2×2.6 | 4.2×2.2×2.7 |
| Weight of machine | TON | 6.5 |
7.5 |
