Hot Sale HDPE 1L 2L 5L 10L Jerry Can Lubricant Oil Bottle Making Machine Extrusion Blow Molding Machine

1 set
MOQ
USD 32900-34200
Price
Hot Sale HDPE 1L 2L 5L 10L Jerry Can Lubricant Oil Bottle Making Machine Extrusion Blow Molding Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Blow Molding Type: Extrusion Blow Molding Machine
Maximum Application Size: 30L
Cooling Water Pressure: 0.6 MPA
Water Consumption: 100 L/Min
Mould Lifespan: > 1,000,000 Cycles
Mold Material: P20, 2316, S136H, Aluminum With Beryllium Copper.
Language Settings: Chinese, English And Other Language As Customer Need
Labor Demand: 1~2 Operetor
After-sales Service Provided: Send Engineer To Customer's Factory
Marketing Type: Ordinary Product
Highlight:

5L Jerry Can Blow Molding Machine

,

2L Jerry Can Blow Molding Machine

,

1L Jerry Can Blow Molding Machine

Basic Infomation
Place of Origin: China
Brand Name: Dawson
Certification: CE
Payment & Shipping Terms
Payment Terms: L/C, T/T
Product Description

Hot Sale HDPE 1L 2L 5L 10L Jerry Can Lubricant Oil Bottle Making Machine Extrusion Blow Molding Machine 0

Hot Sale HDPE 1L 2L 5L 10L Jerry Can Lubricant Oil Bottle Making Machine Extrusion Blow Molding Machine 1

5-10L Jerry Can Blow Molding Machine

The 5 - 10L Double Station Double Die Head Jerry Can Blow Molding Machine is not static in its technology. It is constantly evolving, driven by advancements in various fields and changing market demands.
Automation and Robotics Integration
One of the significant trends in the blow - molding industry is the increasing integration of automation and robotics. In the 5 - 10L Double Station Double Die Head machine, automation can be seen in processes such as mold loading and unloading, and can ejection. Robotic arms can be programmed to handle these tasks with high precision and speed, reducing the need for manual labor and minimizing the risk of human error. This not only improves the overall efficiency of the production process but also allows for continuous operation, as robots can work around the clock without breaks. In the future, we may see even more advanced robotic systems that can perform quality inspections in real - time, further enhancing the quality control process.
Smart Manufacturing and IoT Connectivity
The concept of smart manufacturing, enabled by the Internet of Things (IoT), is also making its way into the blow - molding machine technology. The 5 - 10L Double Station Double Die Head machine can be equipped with sensors that monitor various parameters such as temperature, pressure, and machine vibration. These sensors can send data to a central control system in real - time. Manufacturers can then use this data to optimize the production process, predict maintenance needs, and improve overall machine performance. For example, if the sensor detects a slight increase in the temperature of the heating element, the system can adjust the power supply to prevent overheating and potential damage. In the future, IoT - connected machines may be able to self - diagnose and even self - correct minor issues, reducing downtime significantly.
Sustainable Manufacturing Technologies
With the growing global focus on environmental sustainability, the blow - molding industry is also exploring ways to reduce its environmental impact. The 5 - 10L Double Station Double Die Head machine is likely to see advancements in the use of recycled plastics and energy - efficient production methods. Manufacturers are researching ways to incorporate a higher percentage of recycled HDPE or other plastics into the production process without sacrificing the quality of the jerry cans. Additionally, more efficient cooling and heating technologies are being developed to further reduce energy consumption. In the future, we may see machines that are powered by renewable energy sources, such as solar or wind, making the production process even more sustainable.
Advanced Material Processing
New materials are constantly being developed in the plastics industry, and the 5 - 10L Double Station Double Die Head machine will need to adapt to process these materials. For example, there are emerging bio - based plastics that are more environmentally friendly than traditional plastics. The machine may need to be modified to handle the unique processing requirements of these new materials, such as different melting points and viscosities. In the future, we may also see the use of nanocomposites in jerry can production, which could offer enhanced properties such as increased strength and barrier performance, while still being processed on the blow - molding machine.



Hot Sale HDPE 1L 2L 5L 10L Jerry Can Lubricant Oil Bottle Making Machine Extrusion Blow Molding Machine 2

SPECIFICATIONS UNITS DSB90II
Station   double
Max product volume L 10
Number of die heads Set 1/2/3/4/6
Dry cycle PC/H 700*2
Machine dimension (L*W*H) M 4.4*2.2*2.7
Total weight Ton 11
CLAMPING UNIT
Clamping force
KN 160
Platen opening stroke

mm

290-680
Platen size mm 550*530
Max mould size (W*H) mm 550*530
Platen moving distance mm 620
POWER
Extrusion motor power KW 45
Oil pump motor power18 KW 18.5
Extrusion heating power KW 16
Head heating power KW 8-10
Total power KW 87.5-89.5
EXTRDER UNIT
Screw diameter mm 90
Screw L/D ratio L/D 25
Plasticizing capacity Kg/hour 150
Number of heating zone Zone 4
Max die mouth diameter(single head) mm 200

Hot Sale HDPE 1L 2L 5L 10L Jerry Can Lubricant Oil Bottle Making Machine Extrusion Blow Molding Machine 3Hot Sale HDPE 1L 2L 5L 10L Jerry Can Lubricant Oil Bottle Making Machine Extrusion Blow Molding Machine 4Hot Sale HDPE 1L 2L 5L 10L Jerry Can Lubricant Oil Bottle Making Machine Extrusion Blow Molding Machine 5Hot Sale HDPE 1L 2L 5L 10L Jerry Can Lubricant Oil Bottle Making Machine Extrusion Blow Molding Machine 6Hot Sale HDPE 1L 2L 5L 10L Jerry Can Lubricant Oil Bottle Making Machine Extrusion Blow Molding Machine 7Hot Sale HDPE 1L 2L 5L 10L Jerry Can Lubricant Oil Bottle Making Machine Extrusion Blow Molding Machine 8Hot Sale HDPE 1L 2L 5L 10L Jerry Can Lubricant Oil Bottle Making Machine Extrusion Blow Molding Machine 9Hot Sale HDPE 1L 2L 5L 10L Jerry Can Lubricant Oil Bottle Making Machine Extrusion Blow Molding Machine 10Hot Sale HDPE 1L 2L 5L 10L Jerry Can Lubricant Oil Bottle Making Machine Extrusion Blow Molding Machine 11Hot Sale HDPE 1L 2L 5L 10L Jerry Can Lubricant Oil Bottle Making Machine Extrusion Blow Molding Machine 12Hot Sale HDPE 1L 2L 5L 10L Jerry Can Lubricant Oil Bottle Making Machine Extrusion Blow Molding Machine 13Hot Sale HDPE 1L 2L 5L 10L Jerry Can Lubricant Oil Bottle Making Machine Extrusion Blow Molding Machine 14

DAWSON MACHINE & MOULD GROUP



located in Zhangjiagang city, have more than 18 years' experience in the field of plastic machinery,
injection molding machine, blow molding machine, PET blow molding machine, injection blow molding machine, during the past 18 years, we always force our energy into new areas of plastic machinery, plastic packaging machinery, to update the technology, to learn advanced experience, to confirm new theory and new design, we are forming a unique competitive advantage of our owns.
The machines from our company carry good quality and effective after-sales service, upon the market,
customers from more than 45 countries, we provide complete solution for your plastic industry
business, as well as all sorts of technical support & after-sale services!
