Automatic PET Bottle Blow Molding Machine
Cosmetic/juice/edible oil/medicine/water CSD
This shrink wrapping machine is used to package products with a tight and protective shrink film. It can handle different package sizes and shapes, and the shrink film is heated to conform tightly around the products, providing excellent protection against dust, moisture, and tampering. The machine's adjustable temperature and conveyor speed ensure proper shrinkage of the film, creating a professional and attractive packaging appearance. It is widely used in industries for retail packaging and product bundling.
| Model | ZP1500-6C | |
| Bottle type specification | Cavity | 6 |
| Max.volume | 1.5L | |
| Bottle mouth maximum overall diameter | 28-86mm | |
| Bottle biggest diameter | 65mm | |
| Bottle maximum height | 340mm | |
| Production specification | Theoretical output | 10000BPH |
| Bottle type capacity | 500ML | |
| Bottle type weight | 149 | |
| Bottle type | circular | |
| Power specification | Light tube quantity | 48pcs |
| Light tube power | 2KW | |
| Maximun heating power | 60KW | |
| All electric machine installation | 75KW | |
| Actual consumption | 40%--70% | |
| Air pressure specification | Work pressure | 5-6kg/cm2 |
| Temperature range | 10℃ | |
| Comsumption | 8000kcal/hr | |
| Forzen qater flow | 138L/min | |
