Automatic PET Bottle Blow Molding Machine
Cosmetic/juice/edible oil/medicine/water CSD
The bottle capping machine is designed to cap bottles quickly and accurately. It can handle different types of bottle caps, such as screw caps, snap caps, or corks. The machine's adjustable capping torque ensures a proper seal, preventing any leakage or spoilage of the contents. It has a high-speed capping capacity and can be integrated into existing bottling lines, improving overall production efficiency in industries such as beverages, pharmaceuticals, and cosmetics.
| Model | ZP1500-6C | |
| Bottle type specification | Cavity | 6 |
| Max.volume | 1.5L | |
| Bottle mouth maximum overall diameter | 28-86mm | |
| Bottle biggest diameter | 65mm | |
| Bottle maximum height | 340mm | |
| Production specification | Theoretical output | 10000BPH |
| Bottle type capacity | 500ML | |
| Bottle type weight | 149 | |
| Bottle type | circular | |
| Power specification | Light tube quantity | 48pcs |
| Light tube power | 2KW | |
| Maximun heating power | 60KW | |
| All electric machine installation | 75KW | |
| Actual consumption | 40%--70% | |
| Air pressure specification | Work pressure | 5-6kg/cm2 |
| Temperature range | 10℃ | |
| Comsumption | 8000kcal/hr | |
| Forzen qater flow | 138L/min | |
