Automatic PET Bottle Blow Molding Machine
Cosmetic/juice/edible oil/medicine/water CSD
This machine is specifically designed for filling and sealing tubes. It can handle different viscosities of products and ensures accurate filling volumes. The sealing process is reliable, preventing any leakage or contamination. The machine's operation is highly automated, with features such as automatic tube feeding, filling, and sealing. It is widely used in the cosmetics, pharmaceuticals, and chemical industries to package products in a convenient and hygienic tube format.
| Model | ZP1500-6C | |
| Bottle type specification | Cavity | 6 |
| Max.volume | 1.5L | |
| Bottle mouth maximum overall diameter | 28-86mm | |
| Bottle biggest diameter | 65mm | |
| Bottle maximum height | 340mm | |
| Production specification | Theoretical output | 10000BPH |
| Bottle type capacity | 500ML | |
| Bottle type weight | 149 | |
| Bottle type | circular | |
| Power specification | Light tube quantity | 48pcs |
| Light tube power | 2KW | |
| Maximun heating power | 60KW | |
| All electric machine installation | 75KW | |
| Actual consumption | 40%--70% | |
| Air pressure specification | Work pressure | 5-6kg/cm2 |
| Temperature range | 10℃ | |
| Comsumption | 8000kcal/hr | |
| Forzen qater flow | 138L/min | |
