Automatic PET Bottle Blow Molding Machine
Cosmetic/juice/edible oil/medicine/water CSD
This automatic labeling machine is designed to apply labels accurately and efficiently onto different types of containers. It can handle various label shapes and sizes, and its adjustable labeling speed and precision ensure that each label is placed perfectly on the product. The machine uses advanced sensor technology to detect the position and orientation of the containers, allowing for seamless integration into production lines. It is widely used in industries such as food and beverage, cosmetics, and pharmaceuticals to enhance product appearance and provide important product information.
| Model | ZP1500-6C | |
| Bottle type specification | Cavity | 6 |
| Max.volume | 1.5L | |
| Bottle mouth maximum overall diameter | 28-86mm | |
| Bottle biggest diameter | 65mm | |
| Bottle maximum height | 340mm | |
| Production specification | Theoretical output | 10000BPH |
| Bottle type capacity | 500ML | |
| Bottle type weight | 149 | |
| Bottle type | circular | |
| Power specification | Light tube quantity | 48pcs |
| Light tube power | 2KW | |
| Maximun heating power | 60KW | |
| All electric machine installation | 75KW | |
| Actual consumption | 40%--70% | |
| Air pressure specification | Work pressure | 5-6kg/cm2 |
| Temperature range | 10℃ | |
| Comsumption | 8000kcal/hr | |
| Forzen qater flow | 138L/min | |
