Automatic PET Bottle Blow Molding Machine
Cosmetic/juice/edible oil/medicine/water CSD
The film blowing machine is a crucial piece of equipment in the plastic film manufacturing industry. It is capable of producing a wide range of plastic films with different thicknesses and properties. By precisely controlling the extrusion process and the blowing ratio, the machine can create films with excellent tensile strength, tear resistance, and transparency. These films are widely used in various applications, such as packaging and agriculture, providing reliable protection and preservation for the packaged products.
| Model | ZP1500-6C | |
| Bottle type specification | Cavity | 6 |
| Max.volume | 1.5L | |
| Bottle mouth maximum overall diameter | 28-86mm | |
| Bottle biggest diameter | 65mm | |
| Bottle maximum height | 340mm | |
| Production specification | Theoretical output | 10000BPH |
| Bottle type capacity | 500ML | |
| Bottle type weight | 149 | |
| Bottle type | circular | |
| Power specification | Light tube quantity | 48pcs |
| Light tube power | 2KW | |
| Maximun heating power | 60KW | |
| All electric machine installation | 75KW | |
| Actual consumption | 40%--70% | |
| Air pressure specification | Work pressure | 5-6kg/cm2 |
| Temperature range | 10℃ | |
| Comsumption | 8000kcal/hr | |
| Forzen qater flow | 138L/min | |
