Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm

1
MOQ
USD 15,700 ~ 95,000 / set
Price
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm
Features Gallery Product Description Request A Quote
Features
Specifications
Max. Product Volume: 5 L
Dry Cycle: 1000 PC/H
Screw Diameter: 85 Mm
Screw L/D Ratio: 24 L/D
Screw Drive Power: 18.5 KW
Screw Heating Capacity: 5-6 KW
Clamping Force: 65 KN
Template Size: 290x320 Mm
Size Of Machine: 3.9x2.0x2.6
Weight Of Machine: 5.5 Ton
High Light:

Hdpe Detergent Extrusion Blow Molding Machine

,

1000 PC/H Extrusion Blow Molding Machine

,

Extrusion Blow Molding Machine 85 mm
Basic Infomation
Place of Origin: China
Brand Name: DAWSON
Certification: CE
Model Number: FB85
Payment & Shipping Terms
Packaging Details: Standard Export Packing
Delivery Time: 5-8 work days
Payment Terms: L/C, T/T
Supply Ability: 20 set/month
Product Description

High speed plastic hdpe 2L 3L 4L detergent liquid cleaners chemical bottle making extrusion blow molding machine



DAWSON MACHINERY & MOULD GROUP

High speed Extrusion Blow Molding Machine
Special blow-molding machine for high-speed laundry detergent, dual-station and dual-mould. Under the same floor area and labor cost, the output is much more than that of ordinary machines, and the extra is profit
and automatic configuration from world famous brands to realize the advantages of simple operation
and high automation.
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 0



Machine Model
Bottle size
Production forecast
HIGH SPEED SERIES
Double Station 2 Head
1L
680 BPH
3L
660 BPH
Technical Parameters

Unit
FB-85-25H+S2X2.10BM
Maximum volume
L
3.8L
Screw diameter
MM
85/25
Screw length diameter ratio
/
1:24
Screw speed RPM
RPM
20-60
Clamping force
KN
110
Opening and closing stroke
MM
580-230
Swing travel
MM
650
Maximum plasticizing force
KG/H
130/5
Effective size of template (height x width)
MM
490x400
Number of heating sections of die head
/
5
Extrusion motor power
KW
30/2.2
Servo hydraulic pump motor power
KW
15(use servo hydraulic to save 30-40% power)
Barrel heating power
KW
11/1
Heating power of die head
KW
5.5
Die head servo motor power
KW
5.5
Hot cutter power
KW
2
Total power of equipment
KW
72.2
Actual power used
KW
28-33
Machine weight
TON
11
Input voltage
V
380V, 50 HZ ±10%
Control voltage
V
DC24V
Equipment size
MM
4497x4139x2655







Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 1
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 2
Details Images
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 3



Symmetric Toggle Clamping Structure

对衡式肘节锁模机构




Deceleration Valve for Carriage Movement

移模减速阀
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 4
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 5




All Switches & Breaker use France Schneider

施耐德开关/断路器




Servo Pump for Hydraulic System

伺服油泵液压系统
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 6
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 7




Germany Siemens Controlling System

德国西门⼦控制系统




Digital 100 points
Servo Controller

独⽴显⽰100点伺服厚薄控制器
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 8
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 9




Solid State Relay use TAIWAN FOTEK

固态继电器使用台湾阳明
Professional Workshop
Our professional blow molding machine workshop and service team ...
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 10
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 11
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 12
High Quality Mould
High Quality Blow Molding mould

In the process of plastic blow molding, the mold is a very important part. A good blow mould can make the product production more smoothly, and a good blowing mold can also make the finished product more flexible and beautiful.

We have our own mold production workshop, using high configuration equipment and mold engineers with 16 years of technical experience to customize blow molding mold for you.

- We use the best stainless steel S136H or Aluminium alloy 7075# as mould main material- Necking plate use JAPAN DC53 Heat
treatment to HRC62
- Double neck design available to change in future as a spare part necking
- All mould can be made auto-deflashing or manual deflashing as per customer requests
- Perfect mould cooling design to ensure the best moulding preformace
- Available to provide 2D & 3D product drawing for customers
- Available to send samples to customer for approval the product quality
- We had already made moulds for TOTAL,SHELL,GULF,BMW,YAMAHA,MOBIL,TOYOTA,MENGNIU, HYUNDAI,MENTHOLATUM,UNILEVER,LEE KUM KEE...
Company Profile




DAWSON MACHINERY & MOULD GROUP


Our customers are all around the world.

Vietnam, Australia, Indonesia, Malaysia, Thailand, Sri Lanka, Kazakhstan, Russia, UAE, Saudi Arabia, Malta, Romania, Italy, India, Syria, Ethiopia, Egypt, Sudan, Tunisia, Algeria, Kenya, Nigeria, South Africa, Zimbabwe, Mexico, Guatemala, Ecuador, Colombia, Venezuela, Peru....

We have our own service team in

Saudi Arabia, Colombia, Panama, South Africa ...
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 15

DAWSON MACHINE & MOULD GROUP
located in Zhangjiagang city, have more than 18 years' experience in the field of plastic machinery,
blow molding machine, injection molding machine, PET blow molding machine, injection blow molding machine, during the past 18 years, we always force our energy into new areas of plastic machinery, plastic packaging machinery, to update the technology, to learn advanced experience,
to confirm new theory and new design, we are forming a unique competitive advantage of our owns.
The machines from our company carry good quality and effective after-sales service, upon the market,
customers from more than 45 countries, we provide complete solution for your plastic industry
business, as well as all sorts of technical support & after-sale services!

DAWSON will be your reliable friend in China, and we will always do our best to give you max support!

Customer Photos
We committed to providing customers with plastic machinery & equipment production lines beyond expectations.

Customer satisfaction is our eternal pursuit...
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 16
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 17
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 18
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 19
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 20
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 21
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 22
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 23
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 24
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 25
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 26
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 27
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 28
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 29
Our Service
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 30
Hdpe Detergent Extrusion Blow Molding Machine Toilet Cleaner Bottle 1000 PC/H 85 Mm 31
FAQ

Q: Can we visit your factory?

Sure. We located in Zhangjiagang city which is very near Shanghai. For overseas customers, you can fly to Shanghai Pudong
International Airport. We can
pick you up in the Airport. (or Hongqiao International Airport. ) We also provide visit online by video.

Q: How can we get the exact price of plastic machine?

Contact us with the products size, shape, annual quantity and photo if possible. We can recommend our machine models with
quotation.

Q: Do you provide any spare parts with machine?

Yes, we offer all necessary spare parts before shipment.(contact us for packing list )

Q: How about your after-sale service ?

We offer manual instruction and engineer training before loading,after shipment we provide 24 HRS online support, video technical
support or field installation assist.

Q: What is the lead time?

For customized machine, it takes about 45-50 days after deposit. For stock machine, fast shipment. ( The actual production cycle will vary according to the degree of customization.)

Q: What is the warranty period for your machine ?

12 months warranty for components and technical support .

Q: Do you provide custom machines?

Most of our machines are customized. Our goal is efficiency and stable performance. We design the machines according to customers
products to meet customer' needs.

Q: How can we install the machine when it arrives?

We can send experienced technicians to customer's country for guiding the installation and commission the machine, also train the
customer's employees.

Q: What's DAWSON's advantage?

DAWSON provide customers with turnkey projects. Including plant design, plastic machine and mold installation, debugging, also we
can source the auxiliary equipments for customers. We can ship the full set of machines after testing in our factory. It will save
a lot of cost and time.

DAWSON will be your reliable friend in China, and we will always do our best to give you max support!

can source the auxiliary equipments for customers. We can ship the full set of machines after testing in our factory. It will save
a lot of cost and time.

DAWSON will be your reliable friend in China, and we will always do our best to give you max support!
