Hydraulic Automatic Servo Type Pet Preform Injection Molding Machine Two Color

Minimum Order Quantity : 1 set Price : USD 17,700 ~ 95,000 / set
Packaging Details : Standard Export Packing Delivery Time : 5-8 weeks
Payment Terms : L/C, T/T, Western Union, MoneyGram Supply Ability : 20 sets / month
Place of Origin: CHINA Brand Name: DAWSON
Certification: CE Model Number: BST-3000A

Detail Information

Screw Diameter: 56 Mm Shot Volume(theoretical): 788 Cm³
Shot Weight: 709 G Injection Pressure: 178 MPa
Injection Rate: 210 G/s Screw L/D Ratio: 21.6
Screw Speed: 0-180 Rpm Clamping Force: 3000 KN
Platen Stroke: 560 Mm Heat Power: 15.5 KW
Pump Motor Power: 25 KW Oil Tank Capacity: 370 L
Machine Dimension: 6.5X1.8X1.8 M Machine Weight: 9 T
High Light:

Servo Type Automatic Injection Moulding Machine

,

CE Pet Preform Injection Molding Machine

Product Description

hydraulic automatic servo type hot sale high standard pet preform injection molding machine two color

We committed to providing customers with plastic machinery & equipment production lines beyond expectations.

Customer satisfaction is our eternal pursuit...
DAWSON MACHINERY & MOULD GROUP

Our customers are all around the world.

Vietnam, Australia, Indonesia, Malaysia, Thailand, Sri Lanka, Kazakhstan, Russia, UAE, Saudi Arabia, Malta, Romania, Italy, India, Syria, Ethiopia, Egypt, Sudan, Tunisia, Algeria, Kenya, Nigeria, South Africa, Zimbabwe, Mexico, Guatemala, Ecuador, Colombia, Venezuela, Peru....

Injection Molding Machine
Hydraulic Automatic Servo Type Pet Preform Injection Molding Machine Two Color 0



DAWSON BST Series Injection molding machine is designed for Injection plastic caps, preforms, electronic plastic parts, etc. Machine with demoulding linkage which shorten the plastic parts cycle time.
BST series with high speed, stable performance and it is energy-saving type.
Our customers can get higher production with same labor and cost.

Hydraulic Automatic Servo Type Pet Preform Injection Molding Machine Two Color 1


Hydraulic Automatic Servo Type Pet Preform Injection Molding Machine Two Color 2
Injection Molding Machine Applications

Medical Appliance

Auto Parts

Packaging

Electronic Products

Optical Element

Houseware

Building Components

Plastic injection molding machines are preferred for manufacturing medical products, as these machines offer high precision, accurate, and complex injection molded parts.

Hydraulic injection molding machine is the most popular machine type, primarily because of its long service life and a wide range of applications.The hydraulic injection molding machine consists of a fixed-speed, three-phase motor, and a variable-volume pump.

Hydraulic injection molding machines have a long life, far drive distance, and low maintenance cost.This type of machine helps in significant reduction of production cycle time.

Customers mainly use high-tonnage hydraulic machines for molding large parts. This machine is mainly used for producing high precision plastic components such as automotive parts, caps & closers, consumer goods, electrical & electronics goods, and medical items.

Plastic injection molding machines are predominantly used in manufacturing automotive components, interior wrapping, and assembly parts, such as automotive exteriors, car lenses, interior components, under-the-hood components, and filter components.A strong shift in the use of plastics instead of iron and steel in the automotive industry is expected to drive the plastic injection molding machine market during the forecast period.

Stringent government regulations have forced automotive manufacturers to use plastics instead of other materials such as iron and steel.Rapid economic growth, improved infrastructure, and rising middle-class population in emerging economies have led to an increase in vehicle production and sales, which, in turn, increase the demand for plastic injection molding machines.





Parameters BST-1800 BST-2050 BST-2300 BST-2600
Screw diameter mm 48 48 52 56
Theoretical Shot weight CM3 420 525 658 770
Shot weight gram 378 472 592 690
Clamping force KN 1080 2050 2300 2600
Toggle stroke mm 440 445 480 530
Ejector stroke mm 155 155 155 160
Space between tie bars mm 480*460 490*464 510*510 554*554
Mould thickness mm 180-470 190-470 200-510 200-550
Machine size m 5.3*1.6*1.75 5.4*1.6*1.75 5.7*1.8*2.0 6.1*1.7*1.8
Machine weight ton 5.5 6 6.5 8
​​
Injection Molding Machine Standard Feature
CLAMPING UNIT
    1. New type 5-point toggle device with the advantage of stable movement curve and gentle shock
    2. High-quality mold platen with enough intensity to ensure no out of shape if high-pressure clamping
    3. Hard chrome plated high tensile strength tie bars made of superior alloy with a good wear and corrosion resistance ability
    4. Wear-resistant guide for moving platen
    5. Transducer control clamping stroke
    6. Many step controls for speed and pressure of clamping and opening
    7. Ejection device offer dwell, single, more, vibration function
    8. Differential high-speed clamping
    9. Low pressure mold protection function
    10. Hydraulic mold height adjustment derived by gear with rough and fine operation
    11. Mechanical and electrical dual safety interlock
    12. Automatic centralized lubrication system with far pressure detector
HYDRAULIC UNIT
    1. Proportional pressure and flow control with the advantage of fine adjustment and high precision
    2. Know-how manifold design, compact, reasonable and fast respond
    3. Imported world famous hydraulic valves
    4. Imported world famous hydraulic sealing rings
    5. Import technology hydraulic hose and fittings
    6. Low noise hydraulic system
    7. Oil tank with inner stainless-steel container
    8. Precision oil filter
    9. Oil cooler
CONTROL UNIT
    1. The computer is imported from Industry family. The LCD displaying screen with high clarity has Chinese and English language to display
    2. World famous electrical components
    3. Close-loop PID temperature control with the advantage of high precision.
    4. Deviation preset between high and low temperature. And break control for temperature sensor.
    5. Alarming system in case of cold start and no material in hopper
    6. Transducer control the injection and opening stroke to accuracy of ±0.05mm
    7. 99 steps speed control for increasing and reducing to suit for different technology demands
    8. Self-diagnostic and trouble alarm function
    9. Parameters lock function to avoid being changed
    10. 100 sets of production parameters can be stored into the computer memorial software
    11. Machine can record the quantity of products and automatically stop if up to the required quantity.
    12. Emergency stop device
    13. Alarm lamp


Hydraulic Automatic Servo Type Pet Preform Injection Molding Machine Two Color 3











DAWSON MACHINERY & MOULD GROUP


Our customers are all around the world.

Vietnam, Australia, Indonesia, Malaysia, Thailand, Sri Lanka, Kazakhstan, Russia, UAE, Saudi Arabia, Malta, Romania, Italy, India,Egypt, Sudan, Tunisia, Algeria, Nigeria, South Africa, Zimbabwe, Mexico, Guatemala, Ecuador, Colombia, Venezuela, Peru....

We have our own service team in

Saudi Arabia, Colombia, Panama, South Africa ...


Hydraulic Automatic Servo Type Pet Preform Injection Molding Machine Two Color 4

DAWSON MACHINE & MOULD GROUP
located in Zhangjiagang city, have more than 18 years' experience in the field of plastic machinery,
injection molding machine, blow molding machine, PET blow molding machine, injection blow molding machine, during the past 18 years, we always force our energy into new areas of plastic machinery, plastic packaging machinery, to update the technology, to learn advanced experience,
to confirm new theory and new design.
The machines from our company carry good quality and effective after-sales service, upon the market,
customers from more than 45 countries, we provide complete solution for your plastic industry
business, as well as all sorts of technical support & after-sale services!

DAWSON will be your reliable friend in China, and we will always do our best to give you max support!

Hydraulic Automatic Servo Type Pet Preform Injection Molding Machine Two Color 5
Hydraulic Automatic Servo Type Pet Preform Injection Molding Machine Two Color 6

 Q: Can we visit your factory?

Sure. We located in Zhangjiagang city which is very near Shanghai. For overseas customers, you can fly to Shanghai Pudong
International Airport. We can
pick you up in the Airport. (or Hongqiao International Airport. ) We also provide visit online by video.

Q: How can we get the exact price of plastic machine?

Contact us with the products size, shape, annual quantity and photo if possible. We can recommend our machine models with quotation.

Q: Do you provide any spare parts with machine?

Yes, we offer all necessary spare parts before shipment.(contact us for packing list )

Q: What is the lead time?

For customized machine, it takes about 45-50 days after deposit. For stock machine, fast shipment. ( The actual production cycle will vary according to the degree of customization.)

Q: What is the warranty period for your machine ?

12 months warranty for components and technical support .

Q: Do you provide custom machines?

Most of our machines are customized. Our goal is efficiency and stable performance. We design the machines according to customers products to meet customer' needs.

Q: How can we install the machine when it arrives?

We can send experienced technicians to customer's country for guiding the installation and commission the machine, also train the customer's employees.

Q: What's DAWSON's advantage?

DAWSON provide customers with turnkey projects. Including plant design, plastic machine and mold installation, debugging, also we can source the auxiliary equipment for customers. We can ship the full set of machines after testing in our factory. It will save a lot of cost and time.

DAWSON will be your reliable friend in China, and we will always do our best to give you max support!

Hydraulic Automatic Servo Type Pet Preform Injection Molding Machine Two Color 7
Hydraulic Automatic Servo Type Pet Preform Injection Molding Machine Two Color 8
Hydraulic Automatic Servo Type Pet Preform Injection Molding Machine Two Color 9
