Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle

1
MOQ
USD 15,700 ~ 95,000 / set
Price
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle
Features Gallery Product Description Request A Quote
Features
Specifications
Screw: 76 Mm
Shot Size: 1766 Cm³
Shot Weight: 1590 G
Injection Pressure: 158 Mpa
Injection Rate: 398 G/s
Screw L/D Ratio: 20.7 L/D
Screw Speed: 0-160 R.p.m
Clamping Tonnage: 4800 KN
Mould Thickness: 280-750 Mm
Heat Power: 23.4 KW
Pump Motor Power: 15+25 KW
Machine Dimension: 8.3x2.2x2.2 M
Machine Weight: 16.3 T
Oil Tank Capacity: 600 L
Space Between Tie-bars: 750x720 Mm
Max. Pump Pressure: 16 Mpa
High Light:

Plastic Oil Gallon Injection Molding Machine

,

20L Buckets Injection Molding Machine

,

750 mm Buckets Injection Molding Machine

Basic Infomation
Place of Origin: China
Brand Name: DAWSON
Certification: CE
Model Number: SZ-6500A
Payment & Shipping Terms
Packaging Details: Standard Export Packing
Delivery Time: 5-8 weeks
Payment Terms: L/C, T/T
Supply Ability: 20 sets/month
Product Description

Plastic oil gallon 19L 20L buckets coating color tank Paint bucket with handle making injection molding machine

suitable for making preform,pipe,bottle cap,syringe,plastic toy,bucket...



DAWSON MACHINERY & MOULD GROUP
***EXTRUSION BLOW MOLDING MACHINE EXPERT***


Our customers are all around the world.

Vietnam, Australia, Indonesia, Malaysia, Thailand, Sri Lanka, Kazakhstan, Russia, UAE, Saudi Arabia, Malta, Romania, Italy, India, Syria, Ethiopia, Egypt, Sudan, Tunisia, Algeria, Kenya, Nigeria, South Africa, Zimbabwe, Mexico, Guatemala, Ecuador, Colombia, Venezuela, Peru...

Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 0

Products Description




DAWSON MACHINERY & MOULD GROUP

Injection Molding Machine BST-6500
specialized for making PET preforms , caps , pails, buckets, jars, covers, lids. Special screw for PET products, all machine adapt latest Taiwan control system, Japan YUKEN hydraulic valve for highest quality standard and machine performance. We also able to provide mould designing and manufacturing to help you build up all kinds of plastic items manufacturing.
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 1

Technical Parameters

Parameters SZ-5500 SZ-6500
Screw diameter mm 80 85
Theoretical shot volume cm3 2141 2298
Shot weight gram 1948 2091
Clamping force KN 5500 6500
Toggle stroke mm 820 870
Ejector stroke 210mm 150 260
Space between tie bars mm 810*810 850*850
Mould thickness mm 350~820 350~900
Machine size m 8.4*2.2*2.6 9.3*2.3*2.7
Machine weight ton 23.5 32



Standard Feature
Injection Molding Machine Standard Feature
CLAMPING UNIT
1. New type 5-point toggle device with the advantage of stable movement curve and gentle shock
2. High-quality mold platen with enough intensity to ensure no out of shape if high-pressure clamping
3. Hard chrome plated high tensile strength tie bars made of superior alloy with a good wear and corrosion resistance
ability
4. Wear-resistant guide for moving platen
5. Transducer control clamping stroke
6. Many step controls for speed and pressure of clamping and opening
7. Ejection device offer dwell, single, more, vibration function
8. Differential high-speed clamping
9. Low pressure mold protection function
10. Hydraulic mold height adjustment derived by gear with rough and fine operation
11. Mechanical and electrical dual safety interlock
12. Automatic centralized lubrication system with far pressure detector
HYDRAULIC UNIT
1. Proportional pressure and flow control with the advantage of fine adjustment and high precision
2. Know-how manifold design, compact, reasonable and fast respond
3. Imported world famous hydraulic valves
4. Imported world famous hydraulic sealing rings
5. Import technology hydraulic hose and fittings
6. Low noise hydraulic system
7. Oil tank with inner stainless-steel container
8. Precision oil filter
9. Oil cooler
CONTROL UNIT
1. 1. The computer is imported from Industry family. The LCD displaying screen with high clarity has Chinese and English
language to display
2. World famous electrical components
3. Close-loop PID temperature control with the advantage of high precision.
4. Deviation preset between high and low temperature. And break control for temperature sensor.
5. Alarming system in case of cold start and no material in hopper
6. Transducer control the injection and opening stroke to accuracy of ±0.05mm
7. 99 steps speed control for increasing and reducing to suit for different technology demands
8. Self-diagnostic and trouble alarm function
9. Parameters lock function to avoid being changed
10. 100 sets of production parameters can be stored into the computer memorial software
11. Machine can record the quantity of products and automatically stop if up to the required quantity.
12. Emergency stop device
13. Alarm lamp
SPARE PARTS
█ Operation Manual █ Normal hopper
█ Level pad █ Heater band █ Mold clip
Details Images
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 2
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 3
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 4
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 5
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 6
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 7
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 8
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 9
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 10
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 11
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 12
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 13







Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 14

Customer Photos
We committed to providing customers with plastic machinery & equipment production lines beyond expectations.

Customer satisfaction is our eternal pursuit...
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 15
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 16
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 17
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 18
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 19
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 20
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 21
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 22
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 23
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 24
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 25



Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 26

Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 27

Company View
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 28
Production Line
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 29
FAQ
Plastic Oil Gallon Injection Molding Machine 19L 20L Buckets Coating Paint Bucket With Handle 30

Q: Can we visit your factory?

Sure. We located in Zhangjiagang city which is very near Shanghai. For overseas customers, you can fly to Shanghai Pudong International Airport. We can pick you up in the Airport. (or Hongqiao International Airport. ) We also provide visit online by video.



Q: How can we get the exact price of plastic machine?

Contact us with the products size, shape, annual quantity and photo if possible. We can recommend our machine models with quotation.



Q: Do you provide any spare parts with machine?

Yes, we offer all necessary spare parts before shipment.(contact us for packing list )



Q: How about your after-sale service ?

We offer manual instruction and engineer training before loading,after shipment we provide 24 HRS online support, video technical support or field installation assist.



Q: What is the lead time?

For customized machine, it takes about 45-50 days after deposit. For stock machine, fast shipment. ( The actual production cycle will vary according to the degree of customization.)



Q: What is the warranty period for your machine ?

12 months warranty for components and technical support .


Q: Do you provide custom machines?
Most of our machines are customized. Our goal is efficiency and stable performance. We design the machines according to customers products to meet customer' needs.

Q: How can we install the machine when it arrives?
We can send experienced technicians to customer's country for guiding the installation and commission the machine, also train the customer's employees.

Q: What's DAWSON's advantage?
DAWSON provide customers with turnkey projects. Including plant design, plastic machine and mold installation, debugging, also we can source the auxiliary equipment for customers. We can ship the full set of machines after testing in our factory. It will save a lot of cost and time.

DAWSON will be your reliable friend in China, and we will always do our best to give you max support!and bottles in all shapes.
