Home /Products/Automatic Blow Moulding Machine/Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine

Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine

1
MOQ
USD 15,700 ~ 95,000 / set
Price
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Max. Product Volume: 120L
Dry Cycle: 360 PC/H
Screw Diameter: 100 MM
Screw L/D Ratio: 28 L/D
Screw Drive Power: 55 KW
Screw Heating Capacity: 22 KW
No. Of Heating Zone: 5 Zone
Output Of HDPE: 200 KG/H
Oil Pump Drive Power: 22 KW
Clamping Force: 600 KN
Max. Size Of Mold: 1000x1300
Material Storage: 14 L
Template Size: 1150x1150
Mold Stroke: 550-1350 MM
Size Of Machine: 5.4x2.5x4.5
Weight Of Machine: 15 TON
High Light:

Water Channel Buoy Blow Molding Machine

,

Solar Panel Buoy Extrusion Blow Molding Machine

,

Hdpe Solar Buoys Blow Molding Machine
Basic Infomation
Place of Origin: China
Brand Name: DAWSON
Certification: CE
Model Number: ABLD100
Payment & Shipping Terms
Packaging Details: Standard Export Packing
Delivery Time: 5-8 work days
Payment Terms: L/C, T/T
Supply Ability: 20 set/month
Product Description

Solar Panel Floater making machine plastic extrusion blow molding machine

The whole blow molding machine is equipped with bilingual operation panel
and automatic configuration from world famous brands to realize the advantages of simple operation
and high automation
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 0
Products Description




DAWSON MACHINERY & MOULD GROUP

Extrusion Blow Molding Machine ABLD100
suitable for making medical bed board, pallet, floater, barrel to 120L
The whole blow molding machine is equipped with bilingual operation panel
and automatic configuration from world famous brands to realize the advantages of simple operation
and high automation.

Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 1
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 2
Technical Parameters
Name
Units
ABLD100
Max.product volume
L
120
Screw diameter
MM
100
Screw drive power
KW
55
Output of HDPE
KG/H
200
Oil pump drive power
KW
22
Clamping force
KN
600
Max.size of mold
MM
1000*1300
Template size
MM
1150*1150
Mold stroke
MM
550-1350
Max.die diameter
MM
450
Size of machine
L×W×H
5.4*2.5*4.5
Weight of machine
TON
15
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 3
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 4
Details Images
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 5
High Quality Mould

High Quality Blow Molding mould

In the process of plastic blow molding, the mold is a very important part. A good blow mould can make the product production more smoothly, and a good blowing mold can also make the finished product more flexible and beautiful.


- We use the best stainless steel S136H or Aluminium alloy 7075# as mould main material- Necking plate use JAPAN DC53 Heat
treatment to HRC62
- Double neck design available to change in future as a spare part necking
- All mould can be made auto-deflashing or manual deflashing as per customer requests
- Perfect mould cooling design to ensure the best moulding preformace
- Available to provide 2D & 3D product drawing for customers
- Available to send samples to customer for approval the product quality
- We had already made moulds for TOTAL,SHELL,GULF,BMW,YAMAHA,MOBIL,TOYOTA,MENGNIU, HYUNDAI,MENTHOLATUM,UNILEVER,LEE KUM KEE...
Company Profile



DAWSON MACHINERY & MOULD GROUP

Our customers are all around the world.



Vietnam, Australia, Indonesia, Malaysia, Thailand, Sri Lanka, Kazakhstan, Russia, UAE, Saudi Arabia, Malta, Romania, Italy, India, Syria, Ethiopia, Egypt, Sudan, Tunisia, Algeria, Kenya, Nigeria, South Africa, Zimbabwe, Mexico, Guatemala, Ecuador, Colombia, Venezuela, Peru....

Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 8

DAWSON MACHINE & MOULD GROUP
located in Zhangjiagang city, have more than 18 years' experience in the field of plastic machinery,
blow molding machine, injection molding machine, PET blow molding machine, injection blow molding machine, during the past 18 years, we always force our energy into new areas of plastic machinery, plastic packaging machinery, to update the technology, to learn advanced experience,
to confirm new theory and new design, we are forming a unique competitive advantage of our owns.
The machines from our company carry good quality and effective after-sales service, upon the market,
customers from more than 45 countries, we provide complete solution for your plastic industry
business, as well as all sorts of technical support & after-sale services!


DAWSON will be your reliable friend in China, and we will always do our best to give you max support!


Customer Photos

Customer satisfaction is our eternal pursuit...
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 9
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 10
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 11
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 12
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 13
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 14
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 15
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 16
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 17
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 18
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 19
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 20
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 21
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 22
Our Service
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 23
Solar Panel Floater Making Machine Plastic Extrusion Blow Molding Machine 24
FAQ

Q: Can we visit your factory?

Sure. We located in Zhangjiagang city which is very near Shanghai. For overseas customers, you can fly to Shanghai Pudong
International Airport. We can
pick you up in the Airport. (or Hongqiao International Airport. ) We also provide visit online by video.

Q: How can we get the exact price of plastic machine?

Contact us with the products size, shape, annual quantity and photo if possible. We can recommend our machine models with
quotation.

Q: Do you provide any spare parts with machine?

Yes, we offer all necessary spare parts before shipment.(contact us for packing list )

Q: How about your after-sale service ?

We offer manual instruction and engineer training before loading,after shipment we provide 24 HRS online support, video technical
support or field installation assist.

Q: What is the lead time?

For customized machine, it takes about 45-50 days after deposit. For stock machine, fast shipment. ( The actual production cycle will vary according to the degree of customization.)

Q: What is the warranty period for your machine ?

12 months warranty for components and technical support .

Q: Do you provide custom machines?

Most of our machines are customized. Our goal is efficiency and stable performance. We design the machines according to customers
products to meet customer' needs.

Q: How can we install the machine when it arrives?

We can send experienced technicians to customer's country for guiding the installation and commission the machine, also train the
customer's employees.

Q: What's DAWSON's advantage?

DAWSON provide customers with turnkey projects. Including plant design, plastic machine and mold installation, debugging, also we
can source the auxiliary equipments for customers. We can ship the full set of machines after testing in our factory. It will save
a lot of cost and time.

DAWSON will be your reliable friend in China, and we will always do our best to give you max support!
