Customized Voltage Blow Molding System For Round / Square Plastic Desktop Board

China Customized Voltage Blow Molding System For Round / Square Plastic Desktop Board supplier
Customized Voltage Blow Molding System For Round / Square Plastic Desktop Board supplier Customized Voltage Blow Molding System For Round / Square Plastic Desktop Board supplier Customized Voltage Blow Molding System For Round / Square Plastic Desktop Board supplier Customized Voltage Blow Molding System For Round / Square Plastic Desktop Board supplier

Large Image :  Customized Voltage Blow Molding System For Round / Square Plastic Desktop Board

Product Details:

Place of Origin: SHANDONG,CHINA
Brand Name: UYOUNG MACHINERY
Certification: CE
Model Number: UY-DT

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: disassemble machine at first, wrapped parts with plastic film, put them into containers
Delivery Time: 120 days
Payment Terms: T/T, L/C
Supply Ability: 20 sets per year
Contact Now
Detailed Product Description
Machine Dimension: 9*5.5*7m Total Power: 300kw
Average Power Consumption: 145kw Voltage: Customized
Warranty: 1 Year Application: Pallets, Desktop Board

round, square plastic desktop board, pallet blow molding machine


This machine is suitable to produce different sizes of desktop and pallets with HDPE material. it's full automatic and easy operating.

our company manufactures kinds of blow molding machines, suitable to produce water tanks, chemical drums, pallets, road barriers and so on.

Blow molding technique is a newest technology for plastic products. Compare to the rotational molding, blow molding has the follow advantages:
1. Output can be 4 times than rotational molding.
2. Recycle material can be used which can save the material cost up to 35%.
3. There is almost no failure during producing.
4. Products are more strength and resilience.
5. Easy operating and less workers required.

1. Specification
Model UY-DT
Product range ∮1.2m
Machine dimension(LxWxH) 9*5.5*7m
Machine weight 32ton
Total power 300kw
Average power consumption 145kw
Die-header
Accumulator size 16kg
Heating power 45kw
Extrusion system
Screw diameter 110/110mm
Screw L/D ratio 28/1
Extruder motor power 75/75kw
Heating power 66kw
Plasticizing capacity 350kg/h
Mold clamping unit
Clamping platen size 1600*1800*60mm
Max.mold size 1400*1600mm
Clamping force 1000kn
Hydraulic system
Main oil pump power 45kw
Small oil pump power 7.5kw
Oil tank capacity 1000L


2. Machine overview




         Customized Voltage Blow Molding System For Round / Square Plastic Desktop Board

Die Head

  1. Unique design for the die head to supply even and color clear layers.

  2. Super large accumulator suits for various products.
  3. Die head can go up and down to change molds and adjust the flash according to different molds.



    Customized Voltage Blow Molding System For Round / Square Plastic Desktop Board

MOOG and PLC

  1. 100 adjustment points Moog for parison to control the thickness accurately.
  2. PLC with the remote control provides a prompt and precise checking and maintenance.
  3. Temperature control by PLC makes it easier for adjustment and checking
  4. Data saving and loading offers a easy way of operating


   Customized Voltage Blow Molding System For Round / Square Plastic Desktop Board

Hydraulic Station and Servo Controller

  1. Yuken valves (Japan original) provide more clamping strength and with DZ seals give a stable usage for hydraulic.
  2. Servo controller can save at least 30% energy for clamping motor


   Customized Voltage Blow Molding System For Round / Square Plastic Desktop Board

Clamping System

  1. The double rob clamp design gives 20% more center strength than normal.
  2. Intensive clamping platen to increase the life time of the clamping system.


   Customized Voltage Blow Molding System For Round / Square Plastic Desktop Board

Material Loading and Extruders

  1. Vacuum loaders occupy less spare and provide more stable feeding for the extruders.
  2. 28/1 L/D screw and the whole-covers for the heaters decrease the energy consumption of heating.


3. Payment terms
30% advance shall be paid by T/T when place the order, and 70% balance by T/Tbefore shipment.

4. Delivery time
Delivery time: 120 days
The machine shall be ready for inspection in the seller’s factory 90 days after the seller receives the advance.

5. Packaging
The machine will unfold into small parts, well packaged and put into containers.
