2000L Water Tank Fully Automatic Blow Moulding Machine 210kw Average Power Consumption

Good quality Water Tank Blow Molding Machine for sales
Good quality Water Tank Blow Molding Machine for sales
Good quality Machine , Works great! Highly recommend.

—— Farrukh

Product was sent very quickly and arrived on time and in good shape. Packaging was good to insure no damage to the unit.

—— Darrin Lynn

I'm Online Chat Now

2000L Water Tank Fully Automatic Blow Moulding Machine 210kw Average Power Consumption

China 2000L Water Tank Fully Automatic Blow Moulding Machine 210kw Average Power Consumption supplier
2000L Water Tank Fully Automatic Blow Moulding Machine 210kw Average Power Consumption supplier 2000L Water Tank Fully Automatic Blow Moulding Machine 210kw Average Power Consumption supplier 2000L Water Tank Fully Automatic Blow Moulding Machine 210kw Average Power Consumption supplier 2000L Water Tank Fully Automatic Blow Moulding Machine 210kw Average Power Consumption supplier

Large Image :  2000L Water Tank Fully Automatic Blow Moulding Machine 210kw Average Power Consumption

Product Details:

Place of Origin: SHANDONG,CHINA
Brand Name: UYOUNG MACHINERY
Certification: CE
Model Number: UY-2000-3

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: disassemble machine at first, wrapped parts with plastic film, put them into containers
Delivery Time: 120 days
Payment Terms: T/T, L/C
Supply Ability: 20 sets per year
Contact Now
Detailed Product Description
Product Range: 500-2000L Total Power: 408kw
Average Power Consumption: 210kw After-sales Service Provided: Engineers Available To Service Machinery Overseas,Free Spare Parts
Plastic Processed: HDPE Application: Water Tank, Septic Tank, Pallets

2000L water tank, septic tank blow molding machine, pallet making machine



This machine is suitable to produce 500-2000L three layers plastic water tank, septic tanks, pallets with HDPE material. it's full automatic and easy operating, also it's customized.


Our company is one of the top blow molding machine manufacturers in China. Machine application covers 1 to 6 layers various, including 10L to 10,000L water tank, chemical drum, IBC, pallet, road barriers, table and chairs, plastic boat, jerry can etc.



Our company focuses on the large and super large blow molding machine manufacturing and has formed a perfect team with experience designers, skilled workers, marketing experts and trained after sale service staff.


Blow molding technique is a newest technology for plastic products. Compare to the rotational molding, blow molding has the follow advantages:
1. Output can be 4 times than rotational molding.
2. Recycle material can be used which can save the material cost up to 35%.
3. There is almost no failure during producing.
4. Products are more strength and resilience.
5. Easy operating and less workers required.

1. Specification
Model UY2000-3
Product range 500-2000L
Machine dimension(LxWxH) 12*5.5*7.5m
Machine weight 50ton
Total power 408kw
Average power consumption 210kw
Die-header
Accumulator size 60kg
Heating power 80kw
Extrusion system
Screw diameter 100/110/100mm
Screw L/D ratio 28/1
Extruder motor power 55/75/55kw
Heating power 80kw
Plasticizing capacity 450kg/h
Mold clamping unit
Clamping platen size 1900*2000*60mm
Max.mold size 1600*1900mm
Clamping force 1200kn
Hydraulic system
Main oil pump power 45kw
Small oil pump power 7.5kw
Oil tank capacity 1200L


2. Machine overview




         2000L Water Tank Fully Automatic Blow Moulding Machine 210kw Average Power Consumption

Die Head

  1. Unique design for the die head to supply even and color clear layers.

  2. Super large accumulator suits for various products.
  3. Die head can go up and down to change molds and adjust the flash according to different molds.



    2000L Water Tank Fully Automatic Blow Moulding Machine 210kw Average Power Consumption

MOOG and PLC

  1. 100 adjustment points Moog for parison to control the thickness accurately.
  2. PLC with the remote control provides a prompt and precise checking and maintenance.
  3. Temperature control by PLC makes it easier for adjustment and checking
  4. Data saving and loading offers a easy way of operating


   2000L Water Tank Fully Automatic Blow Moulding Machine 210kw Average Power Consumption

Hydraulic Station and Servo Controller

  1. Yuken valves (Japan original) provide more clamping strength and with DZ seals give a stable usage for hydraulic.
  2. Servo controller can save at least 30% energy for clamping motor


   2000L Water Tank Fully Automatic Blow Moulding Machine 210kw Average Power Consumption

Clamping System

  1. The double rob clamp design gives 20% more center strength than normal.
  2. Intensive clamping platen to increase the life time of the clamping system.


   2000L Water Tank Fully Automatic Blow Moulding Machine 210kw Average Power Consumption

Material Loading and Extruders

  1. Vacuum loaders occupy less spare and provide more stable feeding for the extruders.
  2. 28/1 L/D screw and the whole-covers for the heaters decrease the energy consumption of heating.


3. Payment terms
30% advance shall be paid by T/T when place the order, and 70% balance by T/Tbefore shipment.

4. Delivery time
Delivery time: 120 days
The machine shall be ready for inspection in the seller’s factory 90 days after the seller receives the advance.

5. Packaging
The machine will unfold into small parts, well packaged and put into containers.
